Ayre KX-5 Twenty Line-Level Preamplifier

Brand: Ayre Acoustics
Product Code: AYR-KX5
Warranty: 5 Years
$21,450.00
Qty:
Ayre Acoustics
Truck
Free Shipping On Orders Over $99
Padlock
256-Bit SSL Secure Ordering System
Shield
Australian Warranty On All Products
Please enter your post code to obtain a shipping estimate for this product.
Post Code:
Store Categories

KX-5 Twenty

Arguably the most important component in your system, the KX-5 delivers all of the performance and flexibility you have come to expect from an Ayre product.

Following in the legendary footsteps of the KX-R preamplifier, the Ayre KX-5 lives up to the challenge with dynamics powered by our Diamond output stage and a finesse achieved by eliminating the traditional attenuating volume control with our 46 position Variable Gain Transimpedance (VGT) amplification circuit. Featuring six programmable inputs and our unique Equilock gain stage, the KX-5 will draw you in with its enchanting musicality and drop your jaw with its endless depth of stage.


Key Features

  • Ayre’s Diamond output stage
  • Variable Gain Transimpedance (VGT) volume circuit
  • Ayre’s exclusive Equilock circuit
  • 46 step volume control, each of 1.5 dB
  • Linear analogue power supply
  • Zero-feedback and fully-balanced discrete circuitry
  • High-speed circuit board material
  • Input ground switching for true source isolation
  • Six inputs: four balanced, two single-ended
  • Ayre Conditioner power line RFI filter
  • AyreLink communication system
Specifications
Maximum Input Level Unbalanced Inputs: 8 V RMS, Balanced Inputs: 16 V RMS
Gain Gain variable to match the required output level of the system without the need for attenuation
Input Impedance Unbalanced Inputs: 1 MΩ, Balanced Inputs: 2 MΩ (1 MΩ per Phase)
XLR Input Polarity Pin 1 = Ground, Pin 2 = Non-Inverting (Positive), Pin 3 = Inverting (Negative)
Frequency Response DC – 250 kHz
Power Consumption 40 Watts in Operating Mode, 60 Watts in Operating Mode (Volume Control Active)
Dimensions (W x D x H) 44 x 34 x 10 cm (17.25" x 13.25" x 3.75")
Weight 10.5 kg (23 lb)
