RMB-1587MKII
Rotel’s new RMB-1587MKII 7-channel amplifier continues our heritage of producing high powered, perfectionist amplifiers for multi-channel systems.
Following Rotel's MKII design architecture, the RMB-1587MKII incorporates significant circuit and component upgrades in both the power supply and amplifier stages achieving ultra-low distortion, signal isolation, and high-gain output power efficiently packaged in a single, multi-channel amplifier chassis.
Differing from multi-channel amplifiers whose output drops when driving multiple channels simultaneously, the RMB-1587MKII delivers all 7 channels of Class AB amplification at 155 Watts per channel into 8 ohms, and 250 Watts per channel into 4 ohms with all channels driven.
The RMB-1587MKII is available in both black and silver colours.
Key Features
- 7 x 250 Watts of robust power, 4 Ohms
- Class AB amplifier design
- Massive power supply using Dual Toroidal Transformers
- High quality slit foil capacitors
- Rack ears included
Engineered with Care
Specifications | |
Continuous Power Output | 155 W/Ch (7 Channels Driven, 8Ω), 250 W/Ch (7 Channels Driven, 4Ω), 335 W/Ch (2 Channels Driven, 4Ω) |
Total Harmonic Distortion (THD) | 20 Hz – 20 kHz: <0.03% |
Frequency Response | 10 Hz - 100 kHz +0, -3 dB |
Signal to Noise Ratio (IHF "A" Weighted) | 111 dB |
Gain | 26.6 dB |
Intermodulation Distortion (60 Hz:7 kHz, 4:1) | <0.03% |
Damping Factor (1 kHz, 8Ω) | 330 |
Crosstalk/Separation | >55 db |
Input Sensitivity | Line Level Inputs (RCA): 1.61 V, Line Level Inputs (XLR): 3.4 V |
Input Impedance | Line Level Inputs (RCA): 12 kΩ, Line Level Inputs (XLR): 50 kΩ |
Dimensions (W x H x D) | 431 x 237 x 456 mm (17" x 9.4" x 18") |
Front Panel Height | 5U / 221 mm (8.75") |
Power Requirements | 230 V, 50 Hz |
Power Consumption | 1400 W |
Net Weight | 37.6 kg (82.9 lb) |
BTU Rating (4Ω, 1/8th Power) | 4016 BTU/h |
