Exceptional Power, Immersive Sound

The PA720 is a high-performance power amplifier that delivers 7 channels of efficient Class G amplification. With an impressive 140W per channel, the PA720 is designed to offer the greatest flexibility and power without compromising on control.

Featuring the best-in-class components including a toroidal based power supply, acoustically damped chassis, paralleled transistor output stages and exceptionally low levels of distortion, the PA720 masters the reproduction of music with all its originality and detail for an unmatched level of sound quality and clarity.

Arcam PA720 Power Amplifier

Key Features

  • 7 Channel Power Amplifier
  • 7 x 100W Class G amplification (8 ohm, 20Hz-20kHz, 0.2% THD)
  • Class G amplification with 20W of Class A operation
  • Toroidal transformer
  • Ethernet, RS232 control
  • Switchable RCA or balanced XLR inputs
Continuous Power Output at 0.2% THD per Channel
Seven Channels Driven, 4/8 Ω, 1 kHz 140 W / 100 W
Five Channels Driven, 4/8 Ω, 1 kHz 175 W / 110 W
Two Channels Driven, 4/8 Ω, 1 kHz 225 W / 140 W
Harmonic Distortion, 80% Power, 8 Ω at 1 kHz 0.002%
Input Sensitivity 100 W / 8 Ω RCA: 800 mV RMS, XLR: 1.6 V RMS
Signal/Noise Ratio (A-Wtd) 100 W / 8 Ω 112 dB
Input Impedance 10 kΩ
Frequency Response 20 Hz - 20 kHz +/-0.05 dB
Mains Voltage 110 – 120 V or 220 – 240 V, 50 – 60 Hz
Maximum Power Consumption 1.5 kW
Low Power Standby Consumption 0.5 W
Network Standby Consumption 2 W
Dimensions W x H x D (Including Feet, Control Knob and Speaker Terminals) 433 x 425 x 177 mm
Weight (Net) 18 kg
Weight (Gross) 19.7 kg
