Rotel RA-1592 MKII Stereo Integrated Amplifier
Whether a seasoned audiophile or casual listener, the time has never been better to be a music lover. A near limitless supply of music is at our fingertips accessible via streaming, digital mediums, classic vinyl and more.
Rotel has been designing and manufacturing high fidelity, high quality, high performance audio products for over 60 years accurately rendering audio with exceptional detail and stunning clarity. The RA-1592MKII proudly continues in the tradition and heritage of this iconic brand.
The RA-1592MKII Integrated Amplifier includes circuit design innovations, optimization of audio signal paths and updates to critical power supply components delivering a breathtaking performance with dynamic rhythm and timing.
Utilizing Rotel’s best-in-class preamplifier topology and award winning power amplifier technology, the RA-1592MKII is a no compromise, size-efficient, all-in-one integrated audio product. The RA-1592MKII delivers 200 Watts per channel into 8 ohms powered by Rotel’s in-house manufactured toroidal transformer feeding an array of slit-foil capacitors for rich, deep, controlled, bass energy.
The RA-1592MKII supports your favourite sources including Analogue, XLR, Digital, aptX™ and AAC wireless Bluetooth, PC-USB supporting MQA and 32-bit/384kHz PCM, and Moving Magnet Phono stage. Digital to Analogue conversion utilizes a Texas Instruments premium DAC with precisely tuned output filter circuits delivering unprecedented acoustic detail, wide sound stage and exacting positioning.
The RA-1592KII is certified Roon Tested delivering the best experience using Roon software so you can just enjoy the music.
Selectable A-B speaker outputs, RS232, Ethernet and 12V triggers ensure seamless integration with control systems.
Convenience, performance and value - the RA-1592MKII delivers.
- Certified Roon Tested
- Supports MQA and MQA Studio
- 2 x 350 Watts of robust power, 4 Ohms (2 x 200 Watts, 8 Ohms)
- Moving Magnet Phono input for turntable connection
- Wireless aptX™ and AAC Bluetooth
Engineered with Care
|Continuous Power Output||350 W/Ch 4Ω, 200 W/Ch 8Ω|
|Total Harmonic Distortion (THD)||<0.008%|
|Frequency Response||Line Level Inputs: 10 Hz - 100 kHz (±0.5 dB), Digital Inputs: 10 Hz - 90 kHz (±2 dB), Phono Input: 20 Hz - 20 kHz (±0.5 dB)|
|S/N Ratio (IHF "A" Weighted)||Line Level Inputs: 103 dB, Digital Inputs: 102 dB, Phono Input: 80 dB|
|Intermodulation Distortion (60 Hz:7 kHz, 4:1)||<0.03%|
|Speaker Impedance||4Ω Minimum|
|Input Sensitivity||Line Level Inputs (RCA): 340 mV, Line Level Inputs (XLR): 540 mV, Digital Inputs: 0 dBfs, Phono Input (MM): 5.2 mV|
|Input Impedance||Line Level Inputs (RCA): 100 kΩ, Line Level Inputs (XLR): 100 kΩ, Digital Inputs: 75 Ω, Phono Input (MM): 47 kΩ|
|Input Overload||Line Level Inputs (RCA): 3.5 V, Line Level Inputs (XLR): 5.5 V, Phono Input: 52 mV|
|Preout Level||1.5 V|
|Output Impedance||100 Ω|
|Coax/Optical Digital Input Signals||LPCM (Up to 24-bit/192 kHz)|
|PC-USB||USB Audio Class 1: Up to 24-Bit/192 kHz, USB Audio Class 2: Up to 32-Bit/384 kHz (Driver Installation Required), MQA and MQA Studio: Up to 24-Bit/384 kHz, Roon Tested|
|Dimensions & Weight|
|Dimensions (W x H x D)||431 x 144 x 425 mm (17" x 5.7" x 16")|
|Front Panel Height||3U / 132.6 mm (5.25")|
|Power Requirements||230 V, 50 Hz|
|Power Consumption||500 W|
|Standby Power Consumption||<0.5 W|
|Net Weight||17.63 kg (37 lb)|
|BTU Rating (4Ω, 1/8th Power)||1239 BTU/h|
