The 2-way W250-LCR in-wall model with 5-inch drivers features Monitor Audio's C-CAM cones coupled with a pivoting version of the C-CAM Gold Dome tweeter.
These in-wall models can be used vertically or horizontally: the ideal aspect for centre-channel applications in discreet home theatre systems.
This model also provides high frequency level adjustment for super-fine audio tuning.
|Frequency Response||60 Hz – 30 kHz|
|Nominal Impedance||8 Ohms|
|Sensitivity (1 W @ 1 m)||88 dB|
|Maximum SPL||108 dBA|
|Power Handling (RMS)||100 W|
|Recommended Amplifier Requirements||30 – 100 W|
|Drive Unit Complement||2 x 5" C-CAM Cone Bass Driver, 1 x 1" (25 mm) C-CAM Pivoting Gold Dome Tweeter|
|Adjustment Controls||High Frequency Level Switch (+3 dB / 0 dB / -3 dB)|
|Overall Dimensions (Including Grille)||177.4 x 385.2 mm (7 x 15 3/16")|
|Overall Depth (Including Grille)||105 mm (4 1/8")|
|Mounting Depth||100.2 mm (3 15/16")|
|Cut-Out Dimensions||145 x 353 mm (5 3/4" x 13 7/8"), Required Clearance for Doglegs in Centre Configuration: 400 x 197 mm (15 3/4" x 7 3/4")|
|Fixing Type||Tri-Grip Dog Fixings|
|Construction Material||Mineral Filled ABS, RoHS Compliant|
|Weight||3.76 kg (8.3 lb)|
|Pre-Construction Bracket||WB5LCR Pre-Construction Bracket (Yellow)|
|Sold As||Single Unit|
