CP-WT240LCR
The CP-WT240LCR is a multi-purpose speaker, for portrait or landscape applications as a high performance music or theatre satellite.
Utilising twin 4" C-CAM drivers astride a C-CAM tweeter, the drivers offer greater radiating area working in tandem than a single 6" bass driver.
Key Features
- Pivoting C-CAM Gold Dome tweeter.
- 2 x C-CAM bass drivers.
- High overall efficiency.
- High frequency level adjustment (+/-3 dB).
- Boundary compensation controls.
- Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
- Magnetic and easily removable steel grille.
- Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
- Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.
| Specifications | |
| Frequency Response | 60 Hz – 25 kHz |
| Nominal Impedance | 6 Ohms |
| Sensitivity (1 W @ 1 m) | 88 dB |
| Maximum SPL | 108.8 dBA |
| Power Handling (RMS) | 100 W |
| Recommended Amplifier Requirements | 20 – 100 W |
| Crossover Frequency | 2.6 kHz @ 12 dB / Octave |
| Drive Unit Complement | 2 x 4" C-CAM Cone Bass Driver 1" C-CAM Pivoting Gold Dome Tweeter |
| Adjustment Controls | HF Level Switch (+3 dB / 0 dB / -3 dB), Boundary Compensation Switch |
| Overall Dimensions (H x W) | 217 x 333 mm (8 9/16 x 13 1/16") |
| Overall Depth (Including Grille) | 103 mm (4 1/16") |
| Mounting Depth | 97 mm (3 13/16") |
| Cut-Out Dimensions | 183 x 299 mm (7 3/16 x 11 3/4") |
| Fixing Type | 4 Position Tri-Grip Dog Leg Fixings |
| Construction Material | Mineral Filled ABS Plastic (RoHS 2 Compliant) |
| Weight | 2.5 kg (5 lb 8 oz) |
| Pre-Construction Bracket | WB4LCR Pre-Construction Bracket (Dark Brown) |
| Sold As | Single Unit |
