Features an 8-inch C-CAM bass driver and a pivoting IDC module, housing a 4-inch C-CAM RST inverted midrange driver and a 1-inch C-CAM Gold Dome tweeter.
True 3-way design provides rich midrange detail, higher system output, greater power handling, and superior vocal intelligibility and sound localisation.
Optimum imaging and set-up are established via the pivoting IDC, high frequency (+3 dB /0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.
|Frequency Response||45 Hz – 30 kHz|
|Nominal Impedance||6 Ohms|
|Sensitivity (1 W @ 1 m)||90 dB|
|Maximum SPL||111.6 dBA|
|Power Handling (RMS)||120 W|
|Recommended Amplifier Requirements||30 – 120 W|
|Drive Unit Complement||8" C-CAM Cone Bass Driver, Pivoting IDC Module Housing: 4" C-CAM RST Inverted Mid Range Driver and a 1" C-CAM Gold Dome Tweeter|
|Adjustment Controls||HF Level Switch (+3 dB / 0 dB / -3 dB), Boundary Compensation Switch|
|Overall Dimensions (Including Grille)||441 x 288 mm (17 3/8 x 11 5/16")|
|Overall Depth (Including Grille)||104 mm (4 1/8")|
|Mounting Depth||100 mm (3 15/16")|
|Cut-Out Dimensions||387 x 234 mm (15 1/4" x 9 3/16")|
|Fixing Type||6 Position Tri-Grip Dog Fixings|
|Construction Material||Mineral Filled ABS, RoHS Compliant|
|Weight||3.6 kg (7 lb 14 oz)|
|Pre-Construction Bracket||WB8 Pre-Construction Bracket (Green)|
|Sold As||Single Unit|
