A 6 1/2 inch C-CAM bass driver and a more highly specified version of the C-CAM Gold Dome tweeter offer an extended high-frequency response to 30 kHz, as well as higher output and power handling capacity.
Optimum imaging and set-up are established via a pivoting tweeter, high frequency (+3 dB / 0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.
|Frequency Response||55 Hz – 30 kHz|
|Nominal Impedance||6 Ohms|
|Sensitivity (1 W @ 1 m)||88.5 dB|
|Maximum SPL||107.4 dBA|
|Power Handling (RMS)||65 W|
|Recommended Amplifier Requirements||20 – 65 W|
|Drive Unit Complement||6 1/2" C-CAM Cone Bass Driver, 1" C-CAM Pivoting Gold Dome Tweeter|
|Adjustment Controls||HF Level Switch (+3 dB / 0 dB / -3 dB), Boundary Compensation Switch|
|Overall Dimensions (Including Grille)||370 x 250 mm (14 9/16 x 9 13/16")|
|Overall Depth (Including Grille)||96 mm (3 3/4")|
|Mounting Depth||92 mm (3 5/8")|
|Cut-Out Dimensions||332 x 213 mm (13 1/16 x 8 3/8")|
|Fixing Type||6 Position Tri-Grip Dog Fixings|
|Construction Material||Mineral Filled ABS, RoHS Compliant|
|Weight||2.26 kg (5 lb)|
|Pre-Construction Bracket||WB6 Pre-Construction Bracket (Purple)|
|Sold As||Single Unit|
