Configured with an 8-inch C-CAM RST bass driver and a pivoting IDC module, housing a 4-inch C-CAM RST inverted midrange driver and a 1-inch C-CAM Gold Dome tweeter.
3-way design provides deeper bass, higher system output and greater power handling.
Optional square grille can be used with this model.
|Frequency Response||45 Hz – 30 kHz|
|Nominal Impedance||6 Ohms|
|Sensitivity (1 W @ 1 m)||90 dB|
|Maximum SPL||112 dBA|
|Power Handling (RMS)||150 W|
|Recommended Amplifier Requirements||40 – 150 W|
|Drive Unit Complement||8" C-CAM Cone Bass Driver Featuring RST, Pivoting IDC Module Housing: 4" C-CAM RST Inverted Mid Range Driver and a 1" C-CAM Gold Dome Tweeter|
|Adjustment Controls||HF Level Switch (+3 dB / 0 dB / -3 dB), Boundary Compensation Switch|
|Overall Diameter (Including Grille)||285 mm (11 1/4")|
|Overall Depth (Including Grille)||161 mm (6 5/16")|
|Mounting Depth||157 mm (6 3/16")|
|Cut-Out Hole Diameter||247 mm (9 3/4")|
|Optional Square Grille - Outer Dimensions||285 x 285 mm (11 1/4")|
|Fixing Type||3 Position Tri-Grip Dog Fixings|
|Construction Material||Mineral Filled ABS, RoHS Compliant|
|Weight||3.64 kg (8 lb)|
|Pre-Construction Bracket||CB8 Pre-Construction Bracket (Green)|
|Sold As||Single Unit|
