Features surround mode selection of dipole (diffuse sound) or bipole (direct sound) operation for super-discreet home theatre sound.
Incorporates an 8 inch C-CAM bass driver and dual 1-inch C-CAM Gold Dome tweeters mounted at a precise fixed-angle for optimised performance.
Optional square or premium grille can be used with this model.
|Frequency Response||45 Hz – 30 kHz|
|Nominal Impedance||6 Ohms|
|Sensitivity (1 W @ 1 m)||90 dB|
|Maximum SPL||111.6 dBA|
|Power Handling (RMS)||120 W|
|Recommended Amplifier Requirements||30 – 120 W|
|Drive Unit Complement||8" C-CAM Cone Bass Driver, 2 x 1” C-CAM Fixed Angle Gold Dome Tweeters|
|Adjustment Controls||HF Level Switch (+3 dB / 0 dB / -3 dB), Bipole / Dipole Switch with Additional 12 V Trigger Switching|
|Overall Diameter (Including Grille)||285 mm (11 1/4")|
|Overall Depth (Including Grille)||161 mm (6 5/16")|
|Mounting Depth||157 mm (6 3/16")|
|Cut-Out Hole Diameter||247 mm (93/4")|
|Optional Square Grille - Outer Dimensions||285 x 285 mm (11 1/4")|
|Fixing Type||3 Position Tri-Grip Dog Fixings|
|Construction Material||Mineral Filled ABS, RoHS Compliant|
|Weight||3.2 kg (7 lb)|
|Pre-Construction Bracket||CB8 Pre-Construction Bracket (Green)|
|Sold As||Single Unit|
