A 6 1/2 inch C-CAM bass driver and a more highly specified version of the C-CAM Gold Dome tweeter offer an extended high-frequency response to 30 kHz, as well as higher output and power handling capacity than the other 2-way models.
Optimum imaging and set-up are established via a pivoting tweeter, high frequency (+3 dB / 0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.
Optional square or premium grille can be used with this model.
|Frequency Response||60 Hz – 30 kHz|
|Nominal Impedance||6 Ohms|
|Sensitivity (1 W @ 1 m)||88.5 dB|
|Maximum SPL||108 dBA|
|Power Handling (RMS)||75 W|
|Recommended Amplifier Requirements||20 – 75 W|
|Drive Unit Complement||6.5" C-CAM Cone Bass Driver, 1" C-CAM Pivoting Gold Dome Tweeter|
|Adjustment Controls||HF Level Switch (+3 dB / 0 dB / -3 dB), Boundary Compensation Switch|
|Overall Diameter (Including Grille)||250 mm (9 13/16")|
|Overall Depth (Including Grille)||120 mm (4 3/4")|
|Mounting Depth||116 mm (4 9/16")|
|Cut-Out Hole Diameter||211 mm (8 1/4")|
|Optional Square Grille - Outer Dimensions||249 x 249 mm (9 3/16")|
|Fixing Type||3 Position Tri-Grip Dog Fixings|
|Construction Material||Mineral Filled ABS, RoHS Compliant|
|Weight||2.04 kg (4 lb 8 oz)|
|Pre-Construction Bracket||CB6 Pre-Construction Bracket (Purple)|
|Back Box||CCBOX-R, CMBOX-R|
|Sold As||Single Unit|
