Rotel RMB-1512 Distribution Power Amplifier

No longer do you need to purchase several large amplifiers to obtain a high performance multizone audio system. The RMB-1512 features an advanced Class D design that provides plenty of power (12 x 100 Watts into 8 ohms) for the most demanding multizone audio systems, but never runs the danger of overheating itself or other electronic components placed in the same vicinity.

The RMB-1512 features everything needed for remote operation and custom installation including 12 volt trigger, signal sensing, input bussing, sum-to-mono, buffered link output, front panel attenuation controls, five-way binding posts and screw terminals.

Key Features

  • 12 x 100 Watts of robust power
  • Class D amplifier design
  • Rack ears included
  • Automatic signal sensing
  • 12 volt trigger input

Engineered with Care

Rotel RMB-1512 Multi-Channel Distribution Power Amplifier
Amplifier Class D
Continuous Power Output 100 W/Ch (All Channels Driven, 8Ω)
Total Harmonic Distortion (THD) 20 Hz – 20 kHz <0.03%
Frequency Response 10 Hz - 40 kHz ±1 dB
S/N Ratio (IHF "A" Weighted) 105 dB
Gain 27.2 dB
Intermodulation Distortion (60 Hz:7 kHz, 4:1) <0.03%
Damping Factor 200
Speaker Impedance 4Ω Minimum
Input Sensitivity 1.25 V
Input Impedance 8.3 kΩ
Dimensions & Weight
Dimensions (W x H x D) 431 x 144 x 449 mm (17" x 5.7" x 17.8")
Front Panel Height 3U / 132.6 mm (5.25")
Power Requirements 230 V, 50 Hz
Power Consumption 660 W
Standby Power Consumption 10.8 W
Net Weight 10.9 kg (24 lb)
BTU Rating (4Ω, 1/8th Power) 737 BTU/h
